The SmartMount Universal Tilt Wall Mount series offers the most versatile installation features and mounting options. Horizontal and vertical adjustment abilities allow for post installation leveling and side-to-side positioning, making it easier than ever to find the perfect TV position. Lock the tilt angle at installation to prevent tampering or moving with the IncreLok tilt technology. Security screws provided in the ST660 models deter tampering and theft. The open wall plate design offers total wall access, increasing the electrical and cable management options. The display can now simply be installed by a single person with the Hook-and-Hang system. The Easy-Glide adaptors hook onto the wall plate for an overall quick, simple, and secure installation.

• Universal mount fits displays with mounting patterns up to 824 x 405mm (32.44" W x 15.95" H)
• Adjustable 15 forward tilt and 5 backward tilt for finding the optimal viewing angle
• Easy-GripTM ratcheting handle locks tilt angle into place
• Included IncreLokTM feature offers fixed tilt lock in 5 increments when used
• Up to 0.25" (6mm) of vertical adjustment on each universal display adaptor bracket for post-installation leveling and height adjustment fine-tuning
• Horizontal display adjustment up to 8.00" (203mm) for centering display on wall
• Mounts to wood studs, concrete, cinder block or metal studs (metal stud accessory required)
• Includes all necessary wall and display attachment hardware
• Integrated security options available
• Design is UL listed and tested to four times stated load capacity
